SKU: CHT815
Availability: In Stock
Brand: Simplecom
Category: Docking Stations
100% Guarantee Safe Checkout
The Simplecom CHT815 is a versatile 15-in-1 USB-C MST docking station designed to expand laptop connectivity through a single USB-C port. Featuring dual HDMI 2.0 and one DisplayPort 1.4 outputs, it supports up to three external 4K@60Hz displays simultaneously on Windows systems using MST technology. Ideal for professionals and multitaskers, it delivers crisp, high-resolution visuals for enhanced productivity.
Equipped with five USB-A ports (ranging from USB 2.0 to 10Gbps speeds) and two USB-C data ports supporting SuperSpeed transfers, the dock handles high-speed data for external storage and peripherals efficiently. It also includes dual-slot SuperSpeed SD/microSD card readers for fast media access, a Gigabit Ethernet port for stable wired networking, and a 4-pole TRRS 3.5mm combo audio jack for microphone and headphone use.
The integrated USB-C Power Delivery port supports up to 100W charging, enabling your laptop to stay powered without additional adapters. Crafted in a durable aluminum alloy casing with a rotatable vertical stand, the dock offers both heat dissipation and desktop space-saving convenience. Plug-and-play compatibility means no extra drivers are needed, while system requirements specify USB-C with DisplayPort Alternate Mode support for video output. Note that macOS supports only one extended external display, whereas Windows enables multi-monitor setups with MST.
This docking station is the perfect all-in-one hub for expanding a laptop's connectivity and display capabilities, combining performance, convenience, and sleek design for modern workstation setups.
| Host Interface | USB-C Female |
| Dimensions | 12.6 x 12.1 x 4.2 cm (with stand 13.8cm) |
| MST Support | Yes,triple extended displays on Windows |
| Weight | 350 grams |
| Power Delivery | USB-C PD up to 100W charging |
| Operation Temperature | 0 to 50\u00b0C |
| HDCP Support | HDCP 2.3 compliant |
| Network Port | RJ45 Gigabit Ethernet 10\/100\/1000 Mbps |
| Audio Port | 4-pole TRRS 3.5mm headphone\/mic combo |
| Card Reader | slot SD & microSD,5Gbps SuperSpeed |
| USB-C Data Ports | 1x 5Gbps,1x 10Gbps |
| Display Outputs | HDMI 2.0,1x DisplayPort 1.4 |
| Operating Temperature | 0\u00b0C to 50\u00b0C |
| Material | Aluminum alloy casing |
| Host Interface | USB-C female port |
| USB-A Ports | USB 480Mbps,1x 5Gbps,10Gbps |
| Max Display Resolution | Up to 4K@60Hz per output |
| weight_grams | 350 |
| dimensions_whd | 126 x 121 x 42 mm |
| Power Output | 100 |
| Dimensions (mm) | 126 x 121 x 42 |
| Maximum Resolution | 3840x2160 @ 60Hz per display |
| Power Delivery (Watts) | 100 |
| maximum_displays | 3 |
| maximum_resolution_hdmi | 3840x2160 @ 60Hz |
| Power Input | USB-C PD 3.0 (up to 100W) |
| Model Number | CHT815 |
