SKU: UNVR-Instant
Availability: In Stock
Brand: Ubiquiti
Category: Surveillance Systems
100% Guarantee Safe Checkout
The Ubiquiti Network Video Recorder Instant (UNVR-Instant) is a compact and versatile UniFi Protect NVR designed for small to medium surveillance deployments. It features a dedicated 3.5" HDD bay for local video storage, integrated with a powerful 6-port gigabit PoE switch that simplifies camera connections and power delivery. This device supports up to 6 ultra-high-definition 4K cameras, 8 2K cameras, or 15 Full HD cameras, making it ideal for comprehensive security coverage.
Equipped with a quad-core ARM Cortex-A55 processor running at 1.7 GHz and 4 GB of memory, the UNVR-Instant provides smooth management and recording capabilities using the UniFi Protect platform. It includes an HDMI port acting as a viewport, allowing local live video monitoring on a connected display without the need for a separate client device.
A total PoE power budget of 40 W enables powering multiple cameras directly from the device, with each PoE RJ45 port delivering up to 15.4 W (PSE). The internal AC/DC 60 W power supply supports universal AC input (100–240 VAC).
Designed for flexible installation, the unit can be desktop mounted or attached to walls or DIN rails with included mounting kits. Its durable polycarbonate enclosure weighs just 1.04 kg (2.3 lbs) and operates reliably in environments from 0 to 40 °C and 5 to 95% humidity (non-condensing).
The UNVR-Instant is NDAA compliant and carries certifications including FCC, IC, CE, Electrical Safety, and SRRC, ensuring security and reliability standards are met.
Key Benefits:
| Operating Temperature | 0 \u00b0C to 40 \u00b0C |
| Certifications | NDAA,FCC,IC,CE,Electrical Safety,SRRC |
| Mounting Options | Desktop,wall,DIN-rail (mounts included) |
| Dimensions & Weight | Approx. 1.04 kg (2.3 lbs) |
| Video Output | 1 \u00d7 HDMI port (viewport for local monitoring) |
| Power Supply | Internal AC/DC 60 W power supply,100–240 VAC input |
| Video Inputs Supported | 6 \u00d7 4K cameras \/ 8 \u00d7 2K cameras \/ 15 \u00d7 Full HD cameras |
| Uplink Ports | 1 \u00d7 GbE uplink port |
| PoE Power Budget | 40 W total,max 15.4 W per port (PSE) |
| PoE Ports | 6 \u00d7 GbE PoE RJ45 downlink ports |
| Storage Support | 1 \u00d7 3.5\" HDD bay (max power 11 W) |
| Processor Speed | 1.7 GHz |
| Memory | 4 GB RAM |
| Processor | Quad-core ARM Cortex-A55 |
| Model | UNVR-Instant |
| Storage Options | 1 \u00d7 3.5\" HDD bay |
| video_resolution_max | 3840x2160 |
| network_connectivity | Wired: 6\u00d7 GbE PoE RJ45 downlink ports; 1\u00d7 GbE uplink port |
| operating_temperature_c | 0 to 40 |
| operating_humidity_percent | 5% to 95% |
| weight_kg | 1.04 |
| Operating Humidity | 5% to 95% non-condensing |
| Power Supply | Internal AC/DC 60 W power supply,100–240 VAC input |
| power_budget_watts | 40 |
| Maximum Port Density | 7 |
| Model Number | UNVR-Instant |
| fixed_ports | 6 \u00d7 GbE PoE RJ45 downlink ports |
